Thermal Expansion: Dimensional Control and Accuracy

Thermal Stability and Precision: A Challenge for Technical Systems

Industrial environments subject to temperature variations demand stable, precise materials. Low thermal expansion is essential to guarantee dimensional stability, assembly reliability and component life.

Why is the Coefficient of Thermal Expansion critical?

The CTE (Coefficient of Thermal Expansion), expressed in µm/m-°C, determines how a material expands under heat. A high CTE can cause :

  • Deformation and loss of tolerance
  • Cracks, excessive play or unwanted tightening
  • Contact or sealing defects

Low CTE HPPs are ideal for technical assemblies exposed to heat.


DEMGY selection: Low CTE HPP polymers

Product



CTE (µm/m-°C)



Continuous temp.



Specifications



Applications



Torlon® 4203 (PAI)



~18



260°C



Excellent stability



Bearings, mechanical



PEEK GF30/CF30



~15-25



260°C



Loaded glass/carbon



Connectors, auto



Vespel® SCP-5000 (PI)



~18



320°C



Space vacuum resistant



Space, cryogenics



PPS GF40 (Ryton® R4)



~18-20



220°C



Glass-reinforced



Electronics, precision



PVDF (Kynar® 1000 HD)



~120



140°C



Less stable



Fluids, coatings



PTFE (Teflon® FEP-9302)



~125



200°C



Inert, but not very stable



Seals, insulation



Fiber-reinforced grades (GF/CF) greatly reduce expansion.

Standard plastics & metals: where are the limits?

Material



Typical CTE



Problems



Standard plastics (PA6, POM)



70-150



Large deformations



Aluminum



~23



Good, but heavy



Steel



~12



Stable, but dense



Reinforced HPP



15-25



Low density + high precision


Press Enter to type after or Shift + Enter to type before the widget.

Applications sensitive to thermal expansion

Aerospace

  • Structural components, connectors, insulators
  • Vespel® SCP-5000: functional from -200 to +300°C

Precision mechanics

  • Guide rings, polymer bearings
  • Torlon® 4203: rigid, precise, stable

Electronics & connectors

  • Circuit supports, housings
  • PEEK GF30 / PPS GF40 : thermal compatibility with substrates

Automotive & mobility

  • Engine and gearbox components
  • Thermal resistance + stability = long-term reliability

DEMGY expertise for your thermal needs

Targeted material advice

  • Selection based on CTE, temperature, required rigidity
  • Recommended reinforcements (carbon, glass, mineral)

Controlled processing

  • Heat-compensated machining & injection
  • High-stability additive manufacturing

Dimensional validation

  • Cyclic temperature testing
  • Shrinkage control, internal voltage


Conclusion

Controlling thermal expansion is an essential lever for the functional performance, geometric precision and reliability of technical parts. Thanks to their low CTE and structural stability when hot, the HPPs selected by DEMGY meet the most demanding requirements.
