Extreme thermal performance: a speciality of HPP polymers

In fields such as aerospace, automotive and electronics, extreme temperatures are the norm. Conventional plastics fail. High-performance polymers (HPPs) provide exceptional thermal resistance over an operating range from -200°C to +550°C, while retaining their mechanical properties.

High-temperature challenges: beyond conventional plastics

  • Loss of rigidity from 100-120°C for standard plastics
  • Deformation, creep, embrittlement under prolonged heat
  • Alteration of tolerances and wear resistance

High-temperature plastics (HPP) retain their structure above 250°C in continuous service, some up to 320-550°C.


Cryogenic stress: strength at very low temperatures

  • Risk of breakage, cracking, excessive contraction
  • Loss of elasticity and propagation of internal stresses

But some HPPs, such as Torlon® or Vespel®, operate safely down to -273°C, while remaining structural and functional.


DEMGY range: HPP for extreme temperatures

Product



Min. temp. (°C)



Continuous temp. (°C)



Max. temp. (°C)



Application



Vespel® SCP-5000



-273



320



550



Space, engine, cryogenics



Torlon® 4203



-196



260



280



Mechanical, chemical



KetaSpire® KT-820 CF30



-60



260



315



Automotive, aerospace



Ryton® R4



-70



220



280



Electronics, fluids



Teflon® FEP-9302



-200



200



280



Insulation, wiring



Kynar® 1000 HD



-40



140



200



Coatings, pharma


Press Enter to type after or Shift + Enter to type before the widget.

HPP vs. Metals & Plastics: the comparison

Criteria



Metals



Standard plastics



HPP



Heat resistance



High



Low



Excellent ✅



Chemical resistance



Medium



Low



Very good ✅



Density / weight



High



Low



Low ✅



Heat distortion



Yes



Yes



Low ✅



Electrical insulation



No



Yes



Yes ✅


Press Enter to type after or Shift + Enter to type before the widget.

Fields of application

Aerospace & defense

  • Heat shields, engines, light armor
  • Vespel® SCP-5000: +550°C stability

Automotive & electric mobility

  • Motors, sensors, battery insulation
  • KT-820 CF30 : lightweight and rigid at +315°C

Mechanical industry

  • High-load bearings and bushings
  • Torlon® 4203 : mechanical holding under temperature

Power electronics

  • Heat dissipation, connectors
  • Ryton® R4 and Teflon® FEP: dielectrics + temperature


DEMGY expertise in thermal resistance

Technical support

  • Thermal cycle analysis
  • Polymer selection according to application, pressure, environment

High-temperature processing

  • Reinforced HPP injection molding, machining and compression
  • Post-process heat treatments

Full validation

  • Ageing tests, creep measurement, deformation under load
  • UL, ISO, REACH-compliant material files


Heat-resistant HPP polymers are a reliable alternative to metallic materials in extreme environments. They guarantee stability, safety and lightness, while ensuring constant properties from -200 to +550°C.
